Jøtul F 500 - Connector Clearances (Vertical); Connector Clearances (Horizontal); Mantel and Trim Clearances

19
139681_R06 F 500 Oslo 1/20
Stove clearances Unprotected surface Protected surface NFPA 211
Parallel installation Parallel installation
Side Rear Corner* Side Rear Corner*
Stove- no heatshields 14” A 18” B 13” C 6” D 12” E 9” F
Single wall pipe 355mm 460mm 330mm 150mm 300mm 230mm
Stove with rear heatshield 14” G 10” H 9” I 6” J 10” K 9” L
Single wall pipe 355mm 255mm 230mm 150mm 255mm 230mm
Stove with rear heatshield 14” M 6” N 9” O 6” P 6” Q 6” R
With connector shield 355mm 150mm 230mm 150mm 150mm 150mm
Stove with rear heatshield 14” S 6” T 9” U 6” V 6” W 6” X
With double wall pipe 355mm 150-mm 230mm 150mm 150mm 150mm
Connector Unprotected surface Protected surface NFPA 211
clearances (pipe) Vertical installation Vertical installation
Single wall pipe 18” 12”
460mm 300mm
Single wall pipe 6” 6”
with connector shields 150mm 150mm
Double wall pipe 6” 6”
150mm 150mm
Connector Unprotected surface Protected surface NFPA 211
clearances (pipe) Horizontal installation Horizontal installation
Single wall connector 18” 460mm 12” 300mm
Double wall pipe 6” 150mm 6” 150mm
Mantel and trim Stove to 1” thick or less, side trim 12” 300mm
clearances
Stove to 1” thick or less, top trim 16” 410mm
Stove to mantel- maximum mantel depth 12” 30” 765mm
* Use of the left side load door is prohibited in alcove or
corner installations. Use Side Door Lock Kit # 155850.
Jøtul F 500 Woodstove Clearances
