UNPROTECTED SURFACE PROTECTED SURFACE NFPA 211
STOVE CLEARANCES PARALLEL INSTALLATION PARALLEL INSTALLATION
SIDE REAR CORNER* SIDE REAR CORNER*
Stove- no heatshields 13" A 19" B 13" C 6" D 12" E 9" F
Single wall pipe 330mm 480mm 330mm 150mm 300mm 230mm
Stove with rear heatshield 13"
G 13" H 10" I 6" J 12" K 9" L
Single wall pipe 330mm 330mm 250mm 150mm 300mm 230mm
Stove with rear heatshield 13"
M 8" N 10" O 6" P 8" Q 6" R
With connector shield 330mm 200mm 250mm 150mm 200mm 150mm
Stove with rear heatshield 13"
S 8" T 9" U 6" V 8" W 6" X
With double wall pipe 330mm 200mm 230mm 150mm 200mm 150mm
CONNECTOR UNPROTECTED SURFACE PROTECTED SURFACE NFPA 211
CLEARANCES (pipe) VERTICAL INSTALLATION VERTICAL INATALLATION
Single wall pipe 18" 12"
460mm 300mm
Single wall pipe 7" 7"
with connector shields 180mm 180mm
Double wall pipe 6" 6"
150mm 150mm
UNPROTECTED SURFACE PROTECTED SURFACE NFPA 211
HORIZONTAL INSTALLATION HORIZONTAL INSTALLATION
Single wall connector 18" 460mm 12" 300mm
Double wall pipe 6" 150mm 6" 150mm
MANTEL AND TRIM Stove to 1" thick or less, side trim 11" 280mm
CLEARANCES
Stove to 1" thick or less, top trim 17" 430mm
Stove to mantel- maximum mantel depth 11" 26" 660mm
* ATTENTTION: STOVE AND PIPE CLEARANCES MUST BOTH BE TAKEN INTO
CONSIDERATION. THE GREATER CLEARANCE DICTATES THE STOVES POSITION.
* USE OF THE RIGHT SIDE LOAD DOOR IS PROHIBITED IN ALCOVE AND
CORNER INSTALLATIONS.
12
FIRELIGHT CB WOODSTOVE CLEARANCES
