2. SETTING UP & NAVIGATION
Simply plug in the TC66C measuring device into an USB-C interface of your
device. The TC66C is immediately ready for use.
This measuring device has following keys and functions:
1 (K1): Switches between the values or opens the menu.
2 (K2): Press long to open or leave the menu.
Press short to switch the menu.
3 (PWR): Power switch. When this function is activated, you can use the
power supply of the system. When the function is deactivated, you can use
an autonomous power supply unit. For high-precision and low-voltage
measurements, you can turn this switch to OFF and use the Micro-USB-port
for voltage supply.
4 (PD): PD-Switch. Set this switch to OFF when measuring a device that is
being charged. Set the switch to ON to activate the trigger function.
5: Micro-USB-Port for independent power supply and for connection to the
PC so ware.
1 2 3 4
5
