JOYTECH PK300DC - Page 12

11
Installation direction: door opens inward (PK350DC)
L
K
L=820+10L=820+10
K＜820+540820+540
A
B
Note:Note: LimitLimit stopperstopper mustmust bebe installedinstalled
Figure 12
100 120 140 160 180 200 220 240 260 280 300
100
120
140
160
180
200
220
240
260
280
300
Max 90°
mmmm
A
B
Max 100°
Max 110°
Max 120°
Figure 13
Note: Value B must be close to or equal to the value A to obtain the best mechanical
advantage.
