JRC JMA-5300MK2 - 6

Model JMA-5312-6 JMA-5312-6HS JMA-5322-7 JMA-5322-9 JMA-5322-6HS JMA-5332-12
IMO compliant
Display colour raster scan PPI
Range scale 0.125/0.25/0.5/0.75/1.5/3/6/12/24/48/96 NM
Scanners
Model NKE-2103-6 NKE-2103-6HS NKE-2254-7 NKE-2254-9 NKE-2254-6HS NKE-1130
Antenna length 6ft. 6ft. 7ft. 9ft. 6ft 12ft.
Transmitting power 10kW 25kW 30kW
Transmitting frequency 9410mHz ± 30mHz 3050mHz ± 20mHz
Beam width 3db Hor. 1.2°, Ver. 20° Hor. 1.2°, Ver. 20° Hor. 1.0°, Ver. 20° Hor. 0.8°, Ver. 20° Hor. 1.2°, Ver. 20° Hor. 1.9°, Ver. 25°
Rotation speed 27rpm 48rpm 24rpm 48rpm 24rpm(60/50Hz)
Pulse width (receive freq.) 0.08µs/2250Hz, 0.07µs/2250Hz, 0.2µs/2250Hz,
0.25µs/1700Hz, 0.3µs/1900Hz, 0.4µs/1400Hz,
0.5µs/1200Hz, 0.8µs/750Hz,
0.8µs/750Hz, 1.0µs/650Hz,
1.0µs/650Hz 1.2µs/510Hz
Duplexer circular + diode limiter
Tuning automatic / manual
Ambient condition temperature: -25°C +55°C, relative humidity: 93% @40°C
Processor
Model NDC-1417
Bearing indication north-up / course-up / head-up
Presentation mode RM display with true trail, RM display with relative trail, TM display
EBL 2 (EBL1/EBL2) (center/independent) 000.0° - 359.9°, digital display
VRM 2 (VRM1/VRM2), 0.000 - 100.2nm, digital display
Trail indication 4 stages: short, middle, long, super long (e.g. short: o /0.25/0.5/1/3/6/10/15-min)
Display (optional on JMA-5300Mk2 series BB)
Model NWZ-173
LCD 1280x1024dot (SXGA)
E ective diameter ≥ 250mm
Connection cable 5m (processor-monitor)
Keyboard
Model NCE-5171
Connection cable 5m (processor-keyboard)
Installation cable CFQ-6912-30 standard L= 30m (optional up to 65m)
CFQ-6912-20 (L=20m)
2695110056 (L=40m)
Power supply (voltage) DC 21.6 - 31.2V
DC 24V(DC 21.6 - 31.2V)
1) AC 110/230V
Power consumption (at max wind load) 620W 700W 240W + 1600VA
Ambient condition temperature: -15°C +55°C, relative humidity: 93% @40°C (processor, display, keyboard)
Optional items
2)
Gyro interface unit NCT-59A built-in NDC-1417
2)
ATA unit (30 targets) NCA-877A built-in NDC-1417
2)
ARPA unit (100 targets) NCA-877WA built-in NDC-1417
2)
Performance monitor NJU-85 NJU-84 (standard)
Interswitch box NQE-3141-4A (up to 4 radars), NQE-3141-8A (up to 8 radars)
2)
AIS interface unit NQA-2103 built-in NDC-1417
Plotting function board NDB-34A built-in NDC-1417
AC recti er NBA-5111 - AC 100/110/120/220/230/240V
JMA-5300Mk2 series
– speci cations
© 2008.7 2009.8 CAT.No.Y9-167 (No.685-3-3) A Printed in Japan
All speci cations are subject to change without noti cation.
1) AC 100-115/220-240V (50/60Hz 1Ø). AC power is required for JMA-5332-12 antenna motor scanner.
2) Performance monitor, ARPA or ATA, AIS and gyro unit must be  tted on ships compliant to IMO.
