2-3
① [STBY](standby) Switch
Use this switch to change the power-off state to the power-on state, or the transmission state to the
standby state.
To turn off the power, press the
[STBY] switch and [TX] switch together.
-> See section 3.4.2 on page 3-12.
② [TX](Transmit) Switch
PREHEAT at the upper left of the radar display changes to STANDBY about 90 seconds
after the power is turned on.
Then, press this switch to start transmission.
-> See section 3.4.1 on page 3-12.
③ [EBL1/EBL2] (Electric Bearing Line 1/2) Switch
Use this switch to display and select EBL1/2.
-> See section 3.5.2 on page 3-18.
④ [ALARM ACK] (Alarm Acknowledgement) Switch
Use this switch to acknowledge a failure, target’s approach, or collision alarm.
Press the switch to stop an audible alarm.
If more than one alarm has occurred, the switch needs to be pressed the number of times equivalent
to the number of alarms.
-> See section 3.3.6 on page 3-11.
⑤ [OFF CENT] (Off Center) Switch
Shifts the own ship’s position .
-> See section 3.5.5 on page 3-23.
⑥ [GAIN] (Receiving Sensitivity) Control
Controls the radar’s receiving sensitivity.
To get higher sensitivity, turn the control clockwise.
Suppresses the clutter echo from the sea surface.
To heighten a suppressing effect, turn the control clockwise.
The clutter suppression mode switches back and forth between MANUAL and AUTO each
time the control is pressed.
-> See section 3.4.5 on page 3-14.
⑦ [P-LINE] (Parallel Index Line) Switch
Use this switch to display and select EBL1/2.
-> See section 3.5.4 on page 3-22.
⑧ [BRILL] (Operation LCD Brilliance) Switch
Controls the brilliance of the special LCD monitor.
-> See section 3.3.1 on page 3-9.
⑨ [RAIN] (RAIN/SNOW Clutter Suppression) Control
Suppresses the clutter echo from rain or snow.
To heighten a suppressing effect, turn the control clockwise.
To control this suppressing effect using Trackball, press the control.
-> See section 3.4.7 on page 3-15.
⑩ [DAY/NIGHT] (DAY/NIGHT MODE) Switch
Switches the screen color and brilliance according to each setting.
-> See section 3.3.3 on page 3-9.
To Next Page
