Page 11
Use the following control throws as a starting point, when you have experience and are comfortable
with the model then you can increase or decrease them to suit your flying style.
Aileron: 20mm each way at the tip of aileron,
with 40% exponential
Elevator: 27mm each way at tip of elevator, with
20% exponential
Rudder: 60mm each way at base of rudder, with
no exponential
Flap: 50mm deflection for take off
130mm deflection for landing
Control Throws
