Parts list for the applicator MK-L
No.
Part Name Part No. No. Part Name Part No.
101
Body
MA02-101 133
Hex. Nut M4 type-1
102
Slider
MA02-210 134
Stroke adj. Shaft
MA01-331
103
Copper bar (3.8

x2mm)
135
Stroke adj. Bearing
MA01-332
104
Positioning spring
MA01-214 136
Stroke adj. Plate
MA02-330
105
Positioning pin
MA01-213 137
Hex. Nut
MA01-333
106
Insulation disk
MA01-215 138
Stroke adj. Screw
MA01-334
107
Spring
MA01-216 139
Hook
MA01-475
108
Steel ball
140
Hook pin
MA01-476
109
Wire disk
MA01-211 141
Release lever
MA01-473
110
Shank
MA01-217 142
Release lever pin
MA01-474
111
Cam
MA02-335 143
Pressure pad pin
MA01-472
112
Spring cap
MA01-477 144
Pressure pad
MA01-470
113
Spring block
MA01-479 145
Feed plate
114
Spring
MA01-480 146
Spring anchor
MA01-350
115
Support pin
MA01-343 147
Die block
MA01-105
116
Stripper hanger
MA02-481 148
Die plate
MA02-104
117
Plate (L)
MA02-102 149
Side block
MA02-107
118
Plate (R)
MA02-103 150
Wire block
119
Feed shaft
MA01-338 151
Insulation block
120
Ring nut
MA01-341 152
Block ring
MA01-225
121
E-shaped ret. ring (6

)
153
Crimper (A)
122
Lever block
MA01-340 154
Crimper (B)
123
Adj. Bolt
MA01-339 155
Die holder ring
124
Cam roller
MA01-308A 156
Stripper
125
Cam roller shaft
MA01-337A 157
Guide plate (R)
126
Feed lever (A)
MA01-342 158
Guide plate (L)
127
Feed lever pin
MA01-344 159
Shear blade anvil (A)
128
Feed lever (B)
MA01-345 160
Shear blade anvil (B)
129
Feed finger pin
MA01-347 161
Crimper anvil (A)
130
Feed finger spring
MA01-348 162
Crimper anvil (B)
131
Feed finger
163
Shear blade
132
Returning spring
MA01-349 164
Spacer
