Parts list for the applicator MKS-L
No.
Part Name Part No. No. Part Name Part No.
101
Body
MA03-101 135
Stroke adj. Bearing
MA01-332
102
Slider
MA03-210 136
Stroke adj. Plate
MA03-330
103
Copper bar (3.8

x2mm)
137
Hex. Nut
MA01-333
104
Positioning spring
MA01-214 138
Stroke adj. Screw
MA01-334
105
Positioning pin
MA01-213 139
Spring anchor pin
MA03-352
106
Insulation disk
MA01-215 140
Spring anchor
MA03-350
107
Spring
MA01-216 141
Pressure plate
108
Steel ball (3

)
142
Pressure spring
109
Wire disk
MA01-211 143
Returning spring
MA03-349
110
Shank
MA01-217 144
Feed finger
111
Cam
MA03-335 145
Feed finger holder
112
Die block
MA03-105 146
Stripper bracket
113
Die plate
MA03-104 147
Stripper
114
Side block
MA03-107 148
Stripper screw
115
Support pin
MA01-343
116
Feed plate base
MA03-106 150
Guide plate (R)
117
Adj. Plate
MA03-108 151
Guide plate (L)
118
Adj. Screw
MA03-109 152
Feed plate
119
Feed shaft
MA01-338 153
Spacer
120
Ring nut
MA01-341 154
Crimper (A)
121
E-shaped ret ring (6

)
155
Spacer
122
Lever block
MA01-340 156
Crimper (B)
123
Adj. Screw
MA03-339 157
Punch
124
Cam roller
MA01-308A 158
Shear blade
125
Cam roller shaft
MA01-337A 159
Shear blade spring
126
Feed lever (A)
MA01-342 160
Shear blade supporter
127
Feed lever pin
MA01-344 161
Shear blade base
128
Feed lever (B)
MA01-345 162
Crimper anvil (B)
129
Feed finger pin
MA01-347 163
Crimper anvil (A)
130
Feed finger spring
MA01-348 164
Spacer
131
Plate (L)
MA03-102 165
Scrap cover
132
Plate (R)
MA03-103 166
Wire block
133
Hex. Nut (M4, type-1)
167
Insulation block
134
Stroke adj. shaft
MA01-331 168
Block ring
MA01-225
