Introduction
T60
T60 Hybrid earchlight, equipped with two sets of optical lenses, can illuminate a 16° uniform light column,
whose illumination distance is more than 150m and search area is more than 150 ㎡at the height of 50m.
Adapted to the standard quick-release bracket. A controllable gimbal which can support pan tilt linkage
with the gimbal camera. Support DJI Pilot, brightness adjustment, strong light flash and other modes.
Part Name
1.
DJI SDK
port
Connect
Matrice 30
series.
2.
Quick-Release Bracket
Install payload
3.
Cooling Fan
The wind of the high-efficiency cooling fan to reduce the lamp temperature.
4.
Light Units
Provide long-distance illumination and search.
5.
Gimbal
0
to
-85°
controllable; Support pitch with the gimbal cameara.
6.
T-ypec port
Connect other payloads.
1
3
1
2
4
5
用
于
协
助
安
装
P
6
用
于
协
助
安
装
P
4/11
