Judo QUICKSOFT-UNO User Manual

JUDO QUICKSOFT-UNO 29
JQS-U Spare Parts
41 NG ring 42x48 1 120 0208 8
42 Overflow valve piston 1 220 0414 14
45 Overflow valve spring 1 165 0200 7
46 Overflow valve voltage 1 112 0324 8
50 Ring seal *** 1 163 3102 5
52 O-ring 17x3.5 1 120 0026 2
53 Pressure reducing screen *** 1 112 0373 10
54 Hexagonal nut M5 2 163 3147 1
55 O-ring 10x2.5 1 120 0183 1
56 O-ring 18x2.2 1 120 0195 1
61 Clamping union nut 3 114 0011 5
70 Control disc wheel 1 112 0382 12
71 Cheese head screw M5x35 5 165 0215 2
73 Cheese head screw M5x10 1 162 1116 2
74 Expanding spring 2 165 0186 2
75 Control housing cover 1 112 0274 41
76 O-ring 53x3 1 120 0185 2
77 O-ring 40x3 1 120 0151 1
78 Driving slide ring 1 142 0022 2
79 Driver 1 220 0503 65
80 Wall support, complete 1 2200500 11
86 Rate regulator *** 1 162 0213 8
88 Intake screen * 1 112 0021 14
91 O-ring 9.12 x3.53 1 120 0251 3
92 VSV screw lower part 1 112 0346 4
93 VSV sphere 1 220 0565 17
94 Cheese head screw M5x80 1 165 0195 2
95 Pan-head tapping screw 2.9x16 4 165 0173 1
98 Cam wheel 1 112 0277 6
99 Thrust bearing plate 1 220 0549 16
100 Cheese head screw M5x45 1 165 0251 2
103 Intermediate hose 1 220 0596 1
104 Cover seal * 1 120 0255 3
105 Injector seal * 1 120 0237 8
106 Injector chamber 1 220 0487 25
