INSTALLING THE PEDALS
NOTICE
It’s critical that the pedals are tightened rmly in the crank arm to prevent the pedals
from loosening while riding, which will result in signicant damage to the bike.
1. Idenfy the le and right markings on the pedals. Be sure
to install the pedals on their respecve side.
• “L” is for the le pedal and is installed on the le crank arm.
• “R” is for the right pedal and is installed on the right crank
arm (chain side).
Fig. 13 - Le and Right Idencaon Marks
NOTE: Both pedals ghten toward the front of the e-bike.
2. While keeping the pedal horizontal, carefully hand-start the
threads of the pedal into the crank arm.
INSTALLING THE HANDLEBARS
1. Point the headset towards the front of the bike.
2. Center the handlebar in the headset, taking care not to
damage any wires.
3. Install the clamp and screws. Alternately ghten the screw
side-to-side unl secure.
4. Verify that the front re lines up with the headset.
5. Verify that all headset items are ght.
Fig. 12 - Installing the Handlebars
3. Finish ghtening the pedals using the supplied 15 mm
wrench. The pedals must be very ght. Check and reghten
the pedals aer your rst two rides.
Fig. 14 - Installing Petals
