seconds, then release. You will now enter the setup menu. Here
you can adjust a few sengs to control the behavior of the
e-bike.
AVAILABLE MENU OPTIONS
Unit Power Off Delay
Speed Limit NDW
Backlight Torque
Wheel Size Low Volts
NAVIGATING AND ENTERING A MENU SETTING
Use the “assist up” buon and “assist down” buon to navigate
through the menu. When you have selected a parameter you
wish to adjust, push the power buon once and you will enter
that seng.
You will then have the ability to adjust this seng’s value with
the “assist up” and “assist down” buons. When you have
adjusted the seng to your preference, push the power buon
to exit that seng. Connue pressing and releasing the power
buon unl you have exited out of the setup menu and return
to the main screen.
The parameters you have adjusted will not be programmed into
the system. Check to see if the sengs meet your needs with a
short test-ride. If the sengs need adjustment, follow the setup
instrucons again.
UNIT
The unit seng allows you to select between miles per hour
(mph) and kilometers per hour (kmh).
• mph: miles per hour
• km/h: kilometers per hour
SPEED LIMIT
The speed limit seng allows you to set the speed limit of the
bike.
The bike will accelerate up to the maximum speed specied in
this seng.
CLASSIFICATION SET POWER LIMIT SET PEDAL ASSIST
THROTTLE
OPERATION
USA Class 1 /
750W
Set NDW to 4 20 mph Not allowed
USA Class 2 /
750W*
Set NDW to 4
20 mph
(32 km/h)
20 mph
(32 km/h)
USA Class 3 /
750W
Set NDW to 4
28 mph
(45 km/h)
20 mph
(32 km/h)
Europe 250W / 25
km/h
Set NDW to 1
15.5 mph
(25 km/h)
Not Allowed
Europe S-Pedelec /
45 km/h
Set NDW to 4
28 mph
(45 km/h)
Not Allowed
Off-road mode** Set NDW to 5 28 mph
20 mph
(32 km/h)
*default conguration **please refer to local laws & regulations before using
NOTE: In all instances the throle is limited to 20 mph.
BACKLIGHT
Set the brightness of the backlight to the desired level.
WHEEL SIZE
Set the circumference of the re according to the parcular
wheel specicaon.
OPERATION
The wheel circumference is set in mm (millimeters).
“POWER OFF” DELAY
The “power o” delay mer lets you set the duraon that
bike will remain inacve before the electronics system will
automacally shut down to conserve power.
NDW
The NDW is the pedal assist level limiter. In the default
conguraon pedal assist has 5 modes:
ECO, 1, 2, 3, and SPORT
Adjust the maximum pedal assist level that can be selected by
changing the value of the NDW seng.
NDW SETTING
• 1 - The maximum assist level that can be selected is assist
level 1.
• 2 - The maximum assist level that can be selected is assist
level 2.
• 3 - The maximum assist level that can be selected is assist
level 3.
• 4 - The maximum assist level that can be selected is assist
level SPORT.
• 5 - The maximum assist level that can be selected is assist
level RACE.
TORQUE
The pedal assist system provides you with motor assistance
when you pedal. Choose if you want to use the torque sensor
measurement for the pedal assist. The torque sensor is on
by default. In normal operaon, both the torque sensor and
cadence sensor measurements will be used to determine the
pedal assist support level.
ON: The torque sensor will acvate and the pedal assist will
factor in torque and cadence measurements to determine the
pedal assist support level.
OFF: The torque sensor will be turned o and only the cadence
sensor measurement will be used to determine the pedal assist
support level.
LOW VOLTS
The low voltage seng controls how deeply the baery
discharges. The lower this seng, the lower the baery
discharges.
Studies have shown that avoiding a deep discharge state can
signicantly increase baery life. The “low volts” seng will
determine a limit to the lowest voltage before the baery
pack discharges.
When the motor draws power from the baery pack, the
voltage of the baery will decrease. When the voltage further
decreases and reaches the preset limits, the control system will
automacally limit power so the voltage never decreases below
this pre-set limit.
When the nominal voltage of the pack approaches the low
voltage limits that have been set, very lile power will be
available to propel the e-bike. You must recharge the baery to
regain full power.
