Adjustment Procedures Results of Improper Adjustment
Adjustment Procedures Results of Improper Adjustment
™ Loosen setscrews 1 and 2 when the solenoid is not actuated
(OFF). Adjust the state A by moving the entire unit of solenoid
up or down.
™ Loosen setscrews 1 (one each for both sides) and adjust the
position of the wiper.
Carefully tightn the setscrews while preventing the wiper from
twisting.
