Adjustment Procedures Results of Improper Adjustment
Adjustment Procedures Results of Improper Adjustment
1) Loosen setscrews 1 and 2 when wiper solenoid 3 is not
actuated (OFF). Adjust pin A to state A by moving the entire
unit of wiper solenoid 3.
* For CB type, refer to 2) CB type of (37) Position of the wiper.
1. Loosen setscrew 1 (one each for both sides) and adjust the
position of the wiper.
(Caution) Carefully tighten setscrews 1 while preventing the
wiper from twisting.
