−94 −
2) Sewing common data
1. Press switch 3 in the information screen.
The second screen of sewing common data setting
2. Set the items below in the first screen.
2 : Limiting procedure of max. zigzag width limitation
For the limiting procedure of max. zigzag width
limitation, there are two settings below.
3 : Max.zigzag width limitation value
* Display varies according to the procedure selected in 2.
1) When the center is set in 2 :
Max.zigzag width limitation value (center)
2) When the left/right is set in 2 :
Max.zigzag width limitation value (right)
Max.zigzag width limitation value (left)
5 : Reverse feed limitation value (LZ-2290A-SR only)
Reverse feed limitation value is set with “+”/”-” of
switch 5. In case of the example, set it to -4.0.
6 : Normal feed limitation value (LZ-2290A-SR only)
Normal feed limitation value is set with “+”/”-” of switch
6. In case of the example, set it to 4.0.
8 : Second screen of sewing common data setting is
displayed.
3. Set the items below in the second screen.
4: Reference of stitch base line
For the reference of stitch base line,
there are three settings below.
1) Center
2) Right
3) Left
2: Mirror function setting
Mirror inversion means the function that the reverse pattern stitching is performed after pressing the
mirror inversion switch during temporary stop of sewing.
The sewing patterns that the mirror inversion is possible are scallop, custom, continuous stitching and
cycle stitching.
For the mirror inversion, there are two settings below.
1) Center
2) Left/right
The first screen of sewing common data setting
234
23 4
56
56
**
*
*
8
8
To Next Page
