(Caution)
1. There is the release secton A at the shaft
section of the encoder case B in the rear
of the motor.
2. When the handwheel is held removed,
dust or the like enters from the part and
the sensor section is damaged. As a
result, malfunction of the motor may be
caused.
Caution in disassembling Caution in assembling
(Caution)
1. Take care of the dust when replacing the
motor and install the handwheel quickly.
2. When storing the motor itself for a long
period, install the encoder cover
(installed at the time of delivery of the
motor).
3. Motor setscrew 7 (1 pc.) only located in
the lower section on the right-hand is
shorter in length. Be careful when
assembling.
