LK-1903B
Higher productivity and
Excellent seam quality.
LK-1903B-SS-301
STANDARD
LIQUID CRYSTAL PANEL
(
NEW
)
IP-420U
Operation panel provided
with programmable functions
Higher productivity.
Excellent seam quality.
The machine achieves sewing speed of 2,700sti/min. The machine's
starting, stopping, thread-trimming and automatic presser lifting
speeds have been increased to significantly shorten total cycle time.
Auto-lifter mechanism utilizing a system.
The machine is provided as standard with auto-lifter that uses a
stepping-motor system. This helps reduce operator fatigue.
The sewing starting point can be corrected.
In cases where the needle entry point for button sewing is to be
corrected, the sewing starting point can be corrected without the
adjustment of the relevant mechanism.
Oil stains are eliminated.
Thanks to our advanced dry-head technology, the frame (needle bar
and thread take-up) no longer requires lubrication. This prevents the
material from being stained with lubricating oil.
Eco-friendly power saving
An encoder is installed in the pulse motor, thereby achieving
substantially improved power-consumption saving.
Functional settings, such as pattern numbers and
needle thread tensions can be established through the
operation panel with ease. Distance between holes in a
button can be easily changed by means of pattern
enlargement/reduction feature.
Input and edit data while observing the needle-entry points visually.
The operator can easily check the shape of the pattern displayed on the
wide liquid crystal panel.
Make minor adjustments to data quickly and efficiently. Overall use is
easier than ever before.
The memory storage capability of the main body of the sewing machine
has been dramatically enhanced. Now the USB-ready main body of the
sewing machine uses many different kinds of media. In addition to the
Compact Flash card, the main body of the sewing machine is provided as
standard with a USB connector. Now, data can be input/output to/from
various kinds of media (SD (Secure Digital Card), CF (Compact Flash), SM
(Smart Media), FD (floppy disks) etc.) by means of a USB thumb device
and a card reader.
Standard sewing patterns can be assigned to pattern
keys P1 to P50. Any of the sewing patterns assigned to
the P1 to P25 pattern keys can be activated with a touch
of the corresponding key. This means that workability is
improved by assigning 25 sewing patterns that are most
frequently used to those pattern keys.
As many as 99 different cycle sewing patterns, each of
which combines a maximum of 99 different sewing
patterns, can be stored in the memory.
The machine is provided as standard
with the active tension (electronic thread
tension control mechanism).
Since the machine is provided with an
active tension mechanism, it is able to
set a needle thread tension that matches
various sewing conditions (such as
thread, material and sewing speed) on
the operation panel, store the data in
memory and reproduce it.
The needle thread tension can be
separated according to stitching type or
portion of a seam, such as the beginning
part of the seam, base stitched part,
zigzag stitched part and end of the seam
(fastening stitch).
When the operation panel IP-420U is used in combination with the
active tension, the needle thread tension can be set on a
stitch-by-stitch basis. This helps eliminate undesired thread tension
variations at a multi-layered part of a material or with sewing
direction, thereby contributing to upgraded seam quality.
Just a small quantity of clean oil is supplied from the oil tank to the
hook.
It is also possible to change over the stroke of the auto-lifter from a
onestep stroke to a double-step stroke, which offers easier positioning of
a material on the machine. For the double-step stroke, an intermediate
stopping height can be established on the operation panel.
The work clamp foot lift can be set to a maximum of 13mm.
Many different sewing patterns.
The machine is provided as standard with 50 different sewing
patterns. The machine permits easy changeover of sewing patterns
for effortless execution of an inexhaustible range of sewing
specifications.
The LK-1903B is also able to sew buttons using the same data used
for the LK-1903 (EP-ROM).
Needle thread grasping mechanism helps produce consistent knot
tying at the beginning of sewing. (This device has been factory-set
to “invoking prohibited” status at the time of delivery.)
1.5mm
or more
B
A
Model name
LK-1903B-301
φ
8~
φ
20
φ
1.5 or more
G
F
—
—
G
F
—
—
φ
10~
φ
15
φ
9~
φ
10
φ
8~
φ
9
Button size
Outside diameter
that can be adjusted (mm)
Sewing size (mm)
Length (Y)
Width (X)
Thickness
(mm)
Button clamp
jaw lever
(combination)
Right
Part
No.
Left
A
B
C
Needle hole
guide (mm)
Part No.
Feed plate
φ
2.8
φ
1.6
MAZ15502000 (
□
8.5)
Button type
Max. sewing speed
For shank button
1,500sti/min
Outside diameter
Diameter of hole in button
Button
configuration
Position of hole
in button
Configuration of
shank
Pattern No.
18, 19, 20, 21, 22
MAZ158070BB
(MAZ158070BA)
—
—
MAZ158080BB
(MAZ158080BA)
—
—
MAZ15801000
(14149900)
—
For extra-small button
Option
For large button
φ
15~
φ
32
φ
3.5
φ
2.0
MAZ15701000
MAZ15702000 (
□
12.5)
MAZ157070BB
(MAZ157070BA)
—
—
MAZ157080BB
(MAZ157080BA)
—
—
LK-1903B-302
φ
10~
φ
20
For medium-size button
φ
3.5
φ
2.0
MAZ15601000
MAZ15602000 (
□
10)
14149058
(MAZ155070B0)
(MAZ156070B0)
—
14149157
(MAZ155080B0)
(MAZ156080B0)
—
1.7
(2.2)
2.7
(3.2)
2.0
(2.2)
(2.7)
1.7
(2.2)
(2.7)
(0.9)
φ
10~
φ
20
0~3.5
0~3.5
0~3.0
0~3.0
0~2.5
0~2.5
0~6.5
0~6.5
0~4.5
0~4.5
0~3.5
0~3.5
For small button (accessory)
(
φ
3.5)
(
φ
1.6)
1.6
(1.8)
1.41.6(1.6)
(1.8)
(1.1)
(MAZ15501000)
(14149603)
(D2426284Y00)
14148852
(MAZ155070B0)
(MAZ156070B0)
(B25553720A0)
14148951
(MAZ155080B0)
(MAZ156080B0)
(B25573720A0)
Model name Option
※(1) Standard sewing lengths X and Y given above are given assuming that the scale is 100.
(2) Use the patterns No. 34~50 with hole diameter 1.5mm or less.
※
Parts shown in parentheses ( ) are optional.
1·34
2·35
3
4
5·36
6·37
7
8
9·38
10·39
11
12·40
13·41
14
15·42
16·43
17
6-6
8-8
10-10
12-12
6-6
8-8
10-10
12-12
6-6
8-8
10-10
6-6
8-8
10-10
6-6
8-8
10-10
3.4 3.4
X
(mm)
Y
(mm)
Pattern
No.
Stitch
shape
Standard
length
Standard
length
Sewing
thread
Pattern
No.
Stitch
shape
Standard
length
Standard
length
Sewing
thread
(pcs.)
X
(mm)
Y
(mm)
(pcs.)
18·44
19·45
20
21
22
23·46
24
25
26·47
27
28·48
29
30·49
31
32·50
33
6
8
10
12
16
6
10
12
6-6
10-10
6-6
10-10
5-5-5
8-8-8
5-5-5
8-8-8
3.4
0
3.4
3.0
0
3.4
3.4
2.5
Part No. Name of part
Optional part for shank button
14146054
D1401M1YC0A
MAZ160170A0
40015434
14148209
SL6030892TN (2 pcs.)
MAZ16015000
SD0640321TP
40010103
SL6040892TN (2 pcs.)
MAZ16021000
MTQ300B1400
Pick-up device complete
Needle bar (for TQ-1)
Wiper (asm.)
Moving plate link A
Bushing
Screw
Button support link
Hinge screw
Connecting link
Screw
Needle hole guide
Needle TQ×3 #14
K
B
C
—
K
B
C
—
L
B
C
—
L
B
C
—
D
E
—
—
D
E
—
—
A
(mm)
B
(mm)
Min
1
3
5
Max
9
8
7
4
3
—
MODELS CLASSIFIED BY BUTTON SIZESTABLE OF THE SEWING PATTERNS OPTION
SD SM
mini
SD
CF
MS
USB card reader
USB port
φ
B
φ
C
A
: Engraved marker
