AMS-215D, 221D, 215D P TYPE, 221D P TYPE (September, 2003) 2/3
SPECIFICATIONS
110mm (L)×220mm (W) 160mm (L)×250mm (W)
2,500rpm (when stitch length is 3mm or less)
0.1〜12.7mm
41.2mm
Standard 25mm (max. 30mm)
20mm
Standard 4mm (0.5〜10mm)
Model name
Application
Sewing area
Max. sewing speed
Stitch length
Needle bar stroke
Lift of the feeding frame
Lift of the intermediate
presser
Stroke of intermediate
presser
Needle
(at the time of delivery)
Thread
Hook
Memory medium
Space under the arm
Number of stitches that can
be stored in memory
Number of patterns that
can be input
Enlarging/Reducing facility
Bobbin thread counter
Sewing machine motor
Power consumption
Compressed air and
air consumption
Lubrication
Lubricating oil
Total weight
Dimensions
PROGRAMMING FUNCTIONS
● With its large memory, the machine responds to many different sewing patterns.
Sewing settings can be established and sewing patterns programmed entirely
through the operation panel.
● Ample storage capacity: maximum of 360,000 stitches on a floppy disk, or 691
patterns on a 2DD disk or 999 ones on a 2HD disk.
● A maximum of 20,000 stitches can be input per pattern. With this large storage
capacity, the machine supports embroidery patterns with large numbers of stitches.
● A sewing pattern can be enlarged/reduced without changing the stitch length.
● Functions that are frequently used during pattern data input (regular stitching
(linear, spline), point stitching, jumping, thread trimming, etc.) are allocated to
specific keys on the operation panel. This reduces the time required for input of
pattern data.
2DD/2HD 3.5" micro-floppy disk
Sewing area＋253mm Sewing area＋246mm
Max. 360,000 stitches(max. 20,000 stitches/pattern)
Max. 691 patterns (2DD)/999 patterns (2HD)
1〜400% (0.1% step), by increasing/decreasing the stitch length or the number of stitches
Provided as standard
400W compact AC servomotor (direct-drive system)
Single-phase, 3-phase 600VA
0.5〜0.55MPa (5〜5.5kgf/cm
2
), 1.8N /min
Automatic
JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
175kg
960mm (L)×1,200mm (W)×1,200mm (H) 1,005mm (L)×1,200mm (W)×1,200mm (H)
AMS-215D AMS-215D〈P TYPE〉 AMS-221D AMS-221D〈P TYPE〉
AMS-215DS
Standard
AMS-215DH
For heavy-
weight
materials
AMS-215DS
Standard
AMS-215DH
For heavy-
weight
materials
AMS-221DS
Standard
AMS-221DH
For heavy-
weight
materials
AMS-221DS
Standard
AMS-221DH
For heavy-
weight
materials
DP×5 (#14)
For JE: 134
(Nm100)
#80〜#20
B33〜B69
120/3〜40/3
DP×17 (#18)
For JE: 135×17
(Nm110)
#50〜#2
B33〜B207
120/3〜10/3
DP×5 (#14)
For JE: 134
(Nm100)
#60〜#30
B33〜B46
120/3〜60/3
DP×17 (#18)
For JE: 135×17
(Nm110)
#50〜#8
B33〜B92
120/3〜30/3
DP×5 (#14)
For JE: 134
(Nm100)
#80〜#20
B33〜B69
120/3〜40/3
DP×17 (#18)
For JE: 135×17
(Nm110)
#50〜#2
B33〜B207
120/3〜10/3
DP×5 (#14)
For JE: 134
(Nm100)
#60〜#30
B33〜B46
120/3〜60/3
DP×17 (#18)
For JE: 135×17
(Nm110)
#50〜#8
B33〜B92
120/3〜30/3
Double-capacity
shuttle hook
DP double-capacity
shuttle hook
Double-capacity
shuttle hook
DP double-capacity
shuttle hook
