V050 SERIES (September, 2003) 2/4
This type of cloth puller is best-suited for sewing medium-weight
materials, a process which requires a large feeding amount and well-
controlled straight stitching capability. This puller helps reduce operator
fatigue and enables even low-skilled operators to successfully perform
sewing operation.
This type of cloth puller draws the material between top and bottom
rollers, thus preventing the material from being fed in the wrong
direction and resultant irregular stitching. The cloth puller is especially
effective when sewing newly-developed materials or men's shirts with
shape-keeping treatment. In addition, the cloth puller can be widely used
for knit fabrics or top center plaits, pockets and bottoms of pajamas.
The cloth puller must be used with an exclusive table.
If the V053B or V053D complete is delivered, an exclusive table is
necessary.
FOR 1-NEEDLE, LOCKSTITCH MACHINES
FOR LH SERIES (2-NEEDLE, LOCKSTITCH MACHINES)
WHEN YOU PLACE ORDERS
WHEN YOU PLACE ORDERS
V051 V052 V056A
Type Model Applicable model Feature
Type Model Applicable model Feature
Applicable model
DDL
, DLD models
DLN model
DDL
, DLD/
provided with auto-lifter
DLN/provided with auto-lifter
V053
Proximity type
Proximity type
(provided with auto-lifter)
Cloth puller with a large roller
Cloth puller with a large roller
(provided with an auto-lifter)
Cloth puller with top and
bottom rollers
Cloth puller with a large roller
Cloth puller with a large roller
(for provided with a back
tuking solenoid type)
Cloth puller with top and
bottom rollers
Cloth puller with top and
bottom rollers
(for provided with a back
tuking solenoid type)
V051A
V051B
V051C
V051D
V052A
V052B
*
V053A
V053C*
V053B
V053D
V056A
DDL
, DLD
DLN
DDL
, DLD
DLN
LH series
DDL
, DLD
DLN, DLU
DDL
, DLD
DLN, DLU
The roller is spaced only 28mm from the needle. This makes the roller
highly adaptable to the sewing of sharp curves and extermely short
lengths of material. To avoid interference with the presser foot during
processes such as reverse stitching, the roller comes with automatic
double-stepped stroke lifter that lifts the roller to certain height for turn-
out, and then lifts it again to the highest position of its stroke.
The cloth puller can be widely used for many different types of materials,
from light-weight materials for ladies' dresses, blouses and men's shirts,
to medium-weight materials for blazers and coats.
This type of cloth puller is best-suited for sewing medium-weight
materials, a process which requires a large feeding amount and well-
controlled straight stitching capability. This puller helps reduce operator
fatigue and enables even low-skilled operators to successfully perform
sewing operation.
The puller securelly pulls the material while placing it between the top
and bottom rollers. This means not only the material can be fed in the
correct direction but also material slippage can be avoided.
With its strong pulling force, V056 helps enhance efficiency in the sewing
of large materials and long materials such as curtains and making pin
tucks. The cloth puller must be used with an exclusive table.
For the machine equipped with auto-lifter, it is necessary to install the AK device attaching plate asm.
(part No.: MAV-051900A0) and junction cable (part No.: MAV-051910A0).
Except DDL-9000
For the puller provided with a back tucking solenoid a back tucking solenoid shiftingdevice asm.
(part No.: MAV-053020A0) and junction cable (part No.: MAV-053-030A0) is required.
Code
A
B
C
D
Applicable model
LH series (with a large roller)
LH-3100 series (with top and bottom roller)
LH series (with a large roller/for solenoid shifting type)
LH-3100 series
(with top and bottom roller/for solenoid shifting type)
Code
A
B
C
D
Applicable model
DDL
, DLD models
DDL
, DLD, DLN, DLU/
provided with auto-lifter
Code
A
B
Applicable model
DDL
, DLD, DLN, DLU models
Code
A
Voltage
100V240V
380V440V
Code
A
S
Voltage
100V240V
380V440V
Code
A
S
Except DDL-9000
