V050 SERIES (September, 2003) 3/4
WHEN YOU PLACE ORDERS
V054A V055 V058A
FOR MS SERIES (2-NEEDLE, FEED-OFF-THE-ARM, DOUBLE-CHAINSTITCH MACHINES)
Type Model Applicable model Feature
Cloth puller with a large roller V054A
MS-1190
MS-2260
This type of cloth puller is suited for joining the sides of skirts and
seaming sleeve and side of shirts or blouses. The device employ an
intermittent feed method, which is almost same as the continuous feed
method. This enables the cloth puller to adapt to continuous operation
of the sewing machine, thus leading to higher efficiency.
FOR MO SERIES (OVERLOCK/SAFETY STITCH MACHINES)
Type Model Applicable model Feature
Cloth puller with top and
bottom rollers
V058A MO series
This type of puller securely pulls the material while placing it between the
upper and lower rollers. This means that the material will never be fed in
a wrong direction and the material slippage will not arise.
The tape puller provides a strong pulling force, which is best-suited to the
sewing of heavy materials and long materials such as mats and curtains.
FOR MH SERIES (DOUBLE-CHAINSTITCH MACHINES)
Type Model Applicable model Feature
Proximity type
Cloth puller with a large roller
V055A
V055B
MH-380〜382
MH-481, -5
MH-484, -5
MH-380〜382
MH-481, -5
MH-484, -5
The roller is placed near the needle. It is spaced 30 to 34mm away from
the needle. V055A adapts well to sharp curve sewing and short-distance
sewing that require sharp angle handling of the material. In addition,
the puller is provided with an intermittent feed mechanism. This enables
the puller to adapt to continuous operation of the sewing machine,
thereby achieving a higher degree of efficiency.
The puller is widely applicable to various processes including yoke
attaching to dress shrits and various materials ranging from light-weight
ladies' dresses, blouses and shirts to medium-weight blouson and
pajamas.
V055B is best-suited to the sewing of medium-weight materials which
require large feed amount and accurate straight feeding ability.
V055B helps reduce the operator's fatigue and allows unskilled operators
to operate the sewing machine. The puller comes with an intermittent
feed mechanism. This allows the puller to adapt to continuous operation
of sewing machine, thereby achieving a higher of efficiency.
Applicable model
MS series (with a large roller)
Code
A
Applicable model
Top and bottom roller type for MO
Code
A
Applicable model
Proximity type for MH
Large roller for MH
Code
A
B
Voltage
100V〜240V
380V〜440V
Code
A
S
Provided as standard Options
Roller
Size (mm) Roller material: Polyurethane Roller material: Steel
Roller surface: Plane Roller surface: Tooth
Diameter Width Part No. Part No.
Top roller
55 15 MAUAPA5515K MAUASA5515K
55 35 MAUAPA5535K MAUASA5535K
55 50 MAUAPA5550K MAUASA5550K
Buttom roller
25 80 MAUAPA2580K MAUASA2580K
25 60 MAUAPA2560K MAUASA2560K
● V058A (TOP AND BUTTOM ROLLER TYPE)
To Next Page
