LU-1560N, 1560N-7, 1565N, 1561N, 1561N-7 (September, 2003) 2/5
PSC box Code
For General Single-phase 220〜240V 07
Export 3-phase 200〜220V 11
For JUS(LA)
＊
Single-phase 110〜120V 37
3-phase 220〜240V 38
For CE Single-phase 220〜240V 34
Operation panel Code
Not provided
00000
Operation panel display language: English.
Instruction manual comes in three different languages.
E500B
Operation panel display language: English.
Instruction manual comes in five different languages.
E500C
Motor Code
For General Single-phase
Export 3-phase
200〜240V 60
For JUS(LA)
＊
Single-phase 100〜120V 61
3-phase 200〜240V 62
For CE Single-phase 200〜240V 63
–– Needle gauge correspondence table ––
● PSC box/operation panel for SC ● Motor for SC
● LU-1560N Series
Needle gauge Code
4.8mm (3/16") D
6.4mm (1/4") F
7.9mm (5/16") H
9.5mm (3/8") K
12.7mm (1/2") L
Needle gauge Code
4.8mm (3/16") D
6.4mm (1/4") F
7.9mm (5/16") H
Needle gauge Code
4.8mm (3/16") D
6.4mm (1/4") F
7.9mm (5/16") H
9.5mm (3/8") K
12.7mm (1/2") L
Presser foot Code
Standard S
Center guide A
＊
＊For the gauge groups H, K and L only, the
presser foot group A (equipped with center
guide) can be selected.
＊JUS: North America and Central and South America.
(1) The needle gauges marked with a circle ( 〇) in the table below are prepared as optional parts (separately available).
(2) The needle gauges marked with a circle 〇 are selectable at the time the order is placed.
(1) The needle gauges marked with a circle ( 〇) in the table below are prepared as optional parts (separately available).
(2) The needle gauges marked with a circle 〇 are selectable at the time the order is placed.
–– Needle gauge correspondence table ––
Needle
3.2mm 4.8mm 6.4mm 7.9mm 9.5mm 12.7mm 15.9mm 19.1mm 22.2mm 25.4mm 28.6mm 31.8mm
gauge
(1/8") (3/16") (1/4") (5/16") (3/8") (1/2") (5/8") (3/4") (7/8") (1") (1-1/8") (1-1/4")
Code − DFHKL−−−−−−
LU-1560N
〇〇〇〇〇〇〇〇〇〇〇〇
LU-1560N-7
〇〇〇〇〇〇〇〇〇〇〇−
LU-1565N
−〇〇〇〇〇−−−−−−
Needle gauge Code
6mm B
8mm C
10mm D
12mm E
Needle gauge Code
6mm B
8mm C
10mm D
12mm E
Pneumatic auto-lifter
Code
Pedal switch type
(AK123B)
B
DL device Code
Not provided Z
Provided A
Pneumatic auto-lifter
Code
Pedal switch type
(AK123B)
B
Option Code
Not provided Z
AE-10 (Bobbin thread remaining
amount detecting device)
A
DL device Code
Not provided Z
Provided A
Option Code
Not provided Z
AE-10 (Bobbin thread remaining
amount detecting device)
A
● LU-1561N Series
Needle
4mm 6mm 8mm 10mm 12mm 14mm 16mm 18mm 20mm 22mm 24mm 26mm 30mm
gauge
Code − BCDE−−−−−−−−
LU-1561N
〇〇〇〇〇〇〇〇〇〇〇〇〇
LU-1561N-7
〇〇〇〇〇〇〇〇〇〇〇〇〇
Model
name
Model
name
LU1560N LU1565N LU1560N 70BB
LU1561N
LU1561N 70BB
WHEN YOU PLACE ORDERS
[Without automatic thread trimmer] [With automatic thread trimmer]
[Without automatic thread trimmer] [With automatic thread trimmer]
Gauge for standard
Gauge for LU-2200
SC380 M
