LU-1560N, 1560N-7, 1565N, 1561N, 1561N-7 (September, 2003) 3/5
OPTIONS
Model Part No. Description
DL21
(G kit)
GDL-21000GA0 For installed after the setup of the machine
AE-10
(Kit B)
GAE-10000BA0 For installed after the setup of the machine
Feature
Applicable model: LU-1560N-7, LU-1561N-7
For sewing processes that handle heavy materials or multi-layered
parts of material, the alternating vertical movements of the walking
foot and presser foot can be quickly set to maximum by pressing the
DL switch. The result is beautiful seams free from gathered stitches.
The machine is provided with both hand switch and knee switch.
The bobbin thread remaining-amount detecting device warns the
operator with a buzzing sound and lamp indication of the time for
bobbin thread replacement. This allows the operator to
concentrate on sewing work without concern for the remaining
amount of bobbin thread. Since the device directly detects the
bobbin thread amount remaining, cumbersome setting is no longer
required regardless of the material, thread and process.
Applicable model: LU-1560N, LU-1561N, LU-1565N
Applicable model: LU-1560N, LU-1561N, LU-1565N
＊To use auto-lifter and reverse feed stitching device in combination,
select AK119A or AK119B
Applicable model: LU-1560N-7, LU-1561N-7
Highly operable 3-pedal unit for standing work.
AK119A GAK-A19010A0 Knee switch type
Pneumatic auto-lifter
AK119B GAK-A19010B0 Pedal switch type
AK120A GAK-A20010A0 Knee switch type Pneumatic auto-lifter
AK120B GAK-A20010B0 Pedal switch type (provided with air regulator)
― 213-48552
Pneumatic one-touch type reverse feed stitching device
(provided with air regulator)
H152
MAH-152010A0
Suspended ruler
SS-7151610-SP×2
WP-0621016-SD×2
WP-0610002-KN×2
PK75 ― 3-pedal unit
―
210-06507
Additional spring for presser bar
NS-6110530-SP
210-06408
210-16101
210-06002×3
