JUKI MF-7523-U11-UT - Installation; Installing the machine head onto the table

– 3 –– 3 –‒ 3 ‒
[For the V-belt type]
Attach the supporting board and the rubber seats as shown
in the illustration and properly install the sewing machine.
󰿿
Bolt
󱀀
Spacer
󱀁
Washer
󱀂
Spring washer
󱀃
Nut
󱀄
Supporting board
󱀅
Spring pin
󱀆
Rubber cushion (Black) × 3
󱀇
Rubber cushion (Gray) × 1
1. Installing the machine head onto the table
Semi-submerged type
WARNING :
Do not insert the power plug of the motor into the receptacle until all works have been completed. There
is a danger of injury by being caught in the machine.
WARNING :
The weight of the sewing machine is more than 46 kg. Be sure to perform the work with two persons or
more in case of unpacking, transportation or installation.
󰴺
. INSTALLATION
[For the direct-drive type]
Attach the supporting board and the rubber seats as shown
in the illustration and properly install the sewing machine.
󰿿
Bolt
󱀀
Spacer
󱀁
Washer
󱀂
Spring washer
󱀃
Nut
󱀄
Supporting board
󱀅
Spring pin
󱀆
Rubber cushion (Black) × 2
󱀇
Rubber cushion (Gray) × 2
󰿿
󱀀
󱀁
󱀂
󱀃
󱀄
󱀅
󱀆
󱀇
󰿿
󱀀
󱀁
󱀂
󱀃
󱀄
󱀅
󱀇
󱀆
Semi-submerged type
