– 28 –
No Item Description Range Initial value
P01 Maximum sewing speed The maximum sewing speed is limited with the function
setting number P41.
(It can be set under the Service Level mode.)
Refer to
"■ Model selection table" p.31
for the mod-
el selection (0: General 1: High lift 2: Extra-high lift).
200-P41
0 :
Gen-
eral
1 :
High
lift
2 :
Extra-
high
lift
6500 6000
5500
P02 Stop position selection This function setting number is used for setting the nee-
dle stop position.
(0: The needle stops at its upper position
1: The needle stops at its lower position
2: The needle stop position is not specied)
If you select "6: Intermittent suction (controlled with the
number of stitches)" for the function setting number
"P17 Pedal control suction 1 type" or "P22 Pedal control
suction 2 type", it will not be allowed to select "2: The
needle stop position is not specified" for this function
setting number P02.
0-2 0
P03 Soft start ON / OFF This function setting number is used for setting ON /
OFF of the soft-start function.
(0: OFF 1: ON)
0-1 0
P04 Soft-start sewing speed This function setting number is used for setting the soft-
start sewing speed at the beginning of sewing.
200-1500 400
P05 Number of soft-start stitch-
es
This function setting number is used for setting the num-
ber of stitches to be sewn with the soft-start function at
the beginning of sewing.
1-15 2
P06 Minimum number of revo-
lutions
This function setting number is used for setting the mini-
mum value of the number of revolutions.
200-500 200
P12 Number of times of manual
thread trimming
In the case the manual switch is connected to the sew-
ing machine, this function setting number is used for
setting the number of times of thread trimming carried
out when the switch is manually pressed.
1-5 1
P13 Interval of time between
continuous manual thread
trimming operations
In the case the number of times of manual thread trim-
ming set for "P12" is "2 or more", the interval of time be-
tween two consecutive thread trimming operations set
for this function setting number "P13" is to be used.
30-990 50
P15 Presser-foot lifting protec-
tion time
This function setting number is used for setting the ON
time during which the presser foot is held lifted.
0-60 5
P16 Presser foot lifting switch This function setting number is used for setting ON /
OFF of the presser foot lifting operation when the back
part of the pedal is depressed.
1: The presser foot lifting operation is carried out.
0: The presser foot lifting operation is not carried out.
0-1 1
P17 Pedal control suction 1 This function setting number is used for selecting the
operation of the device connected to the suction 1.
0: OFF
1: Front suction; 2: Rear suction
3: Front and rear suction; 4: Long suction;
5: Intermittent suction (controlled by time);
6: Intermittent suction (controlled by the number of
stitches)
In the case "2: The needle stop position is not specied"
is selected for "P02 Stop position selection", "6: Inter-
mittent suction (controlled by the number of stitches)"
cannot be selected for this function setting.
0-6 1
P18 Front suction operating
time for pedal control suc-
tion 1
In the case "1" or "3" is selected for "P17", the suction
1 is kept in the operating state for the period of time set
for this function setting number "P18" when the front
part of the pedal is depressed to start sewing. Unit [ms]
0-5000 300
P19 Rear suction operating
time for pedal control suc-
tion 1
In the case "2" or "3" is selected for "P17", the suction
1 is kept in the operating state for the period of time set
for this function setting number "P19" when the back
part of the pedal is strongly depressed. Unit [ms]
0-5000 300
P20 Intermittent suction oper-
ating time for pedal control
suction 1
In the case "5" is selected for "P17", the suction 1 is
kept in the operating state for the period of time set for
this function setting number "P20" when the sewing
machine carries out sewing. The suction 1 carries out
operation and non-operation of suction alternately in
repetition. Unit [ms]
0-9000 200
6-4. Function setting table
