ENGLISH
36
Accessories
Wheels – 2 Screws – 2, washers – 4.
Hose – outgoing water Hose – incoming water
Feet – 2. Filter
Make sure all accessories are included when the unit is unpacked.
INSTALLATION
Assembly of feet and wheels
Unpack the unit and its accessories. Place the unit 220–250 mm above the ground on a stable surface,
for example a plastic bin. Screw the two feet into the brackets.
Place a washer on each side of the wheels and insert a screw through the wheel. Tighten the screws
using an adjustable spanner.
Lift down the pool heat pump so that it stands firmly on its feet and wheels.
NOTE! Exercise care when lifting the pool heat pump down, so that it does not tip over.
Connection of the water hoses
Remove the protective adhesive labels from the hoses. Connect the hose for the incoming water to the
connection for the incoming water. Connect the hose for the outgoing water to the connection for the
outgoing water. Note tighten the couplings by hand and clockwise.
