Menu structure of the paperless recorder
v Chapter 8 „Device Manager“
v Chapter 7 „Memory Manager“
v Chapter 6 „Alarm and Event Lists“
v Chapter 4 „Visualization“
v Chapter 5 „Memory Presentation (History)“
New device functions
The device software version 187.03.xx is replaced by version 187.04.xx. The following additional
functions are available with the new version:
•additional horizontal recorder image; applicable for curve presentation, for binary presentation,
for display of a closed batch, and for memory presentation
•Expansion of the external inputs from 24 to 54
•Expansion of the external texts from 9 to 27
•Time synchronization through SNTP
•New web server
•Modbus slave monitoring (timeout monitoring)
The device software can be checked in the menu Device manager
Î Device info Î Version Î
SW version.
