JUNCTEK JDS8080 - Parameter Setting Procedures (Display)

JUNCTEK
JDS8000 Series User’s Manual
14
Table 2-3-1 PSG9000 display interface diagram instructions
No.
Instructions
No.
Instructions
1
Soft key menu bar
5
Amplitude
2
Current channel output
status
6
Offset
3
Waveform display
7
Duty cycle
4
Frequency
8
Phase
(1) Soft Key Menu Bar
Display the operation menu of the function (interface) selected currently.
(2) Current Channel Output Status
Indicates the current channel selection state and switch state. "ON" means the
channel output is turned on, and "OFF" means off.
In the main interface, press【OUT】key to control the output state of CH1 and
CH2 at the same time.
Note: Two channels can be turned on at the same time, but cannot be selected
at the same time.
(3) Waveform Display
Display the waveform currently in the main channel.
(4) Frequency
Press the soft key 【Freq】 to highlight the parameter "Frequency". At this time,
use the direction keys to move the cursor to select the digit to be edited, and
then rotate the knob to modify the value. You can also press the InBox key, the
input box will pop out, input the value and select the corresponding value. To
modify the value, turn the knob to switch the frequency unit (MHz, kHz, Hz,
MHz, μHz).
(5) Amplitude
Display the amplitude of the current waveform of the current channel. Press
the corresponding 【Ampl】 soft key to highlight “Amplitude”, use the direction
keys to change the digit, and use the knob to change the parameters. You can
also set the value by pressing the InBox key and input specific value to modify
the set value, the amplitude unit (Vpp).
(6) Offset
Display the waveform DC offset of the current channel. Press 【Offset】 to
highlight “Offset” and use the direction keys to change the digit and knob to
modify this parameter.You can also set the value by pressing the InBox key
and input specific values, the offset unit (V).
