JUNCTEK
JDS8000 Series User’s Manual
(7) Duty Cycle
Display the waveform duty cycle of the channel. Press
【
Duty
】
to highlight
“Duty” and use direction keys to change the digit and knob to modify this
parameter. You can also set the value by pressing the InBox key and input
specific values, The duty cycle unit
（
%
）
.
(8) Phase
Display the phase of the current waveform. After pressing the corresponding
【
Phase
】
soft key, use the direction keys to change the digit and the knob to
modify this parameter.You can also set the value by pressing the InBox key
and input specific values to adjust the parameters.
