1001.GB
D 8
5.2 Remove battery by lifting it upwards (truck with wheel-arm lifting device)
– Withdraw the battery connector (3).
f
The battery cable of the truck must be laterally led outside. While removing the bat-
tery, make sure that the cable is not squeezed.
– Attach hoisting gear to the hoisting ears (9).
– Lift out the battery.
The re-assembly can be performed by reversing the above actions; pay attention to
the correct mounting position and battery connection.
39
1001.GB
D 8
5.2 Remove battery by lifting it upwards (truck with wheel-arm lifting device)
– Withdraw the battery connector (3).
f
The battery cable of the truck must be laterally led outside. While removing the bat-
tery, make sure that the cable is not squeezed.
– Attach hoisting gear to the hoisting ears (9).
– Lift out the battery.
The re-assembly can be performed by reversing the above actions; pay attention to
the correct mounting position and battery connection.
39
