Jungheinrich ERC 14 - Description of Controls and Indicating Instruments

0602.GB
E 2
2 Description of controls and indicating instruments
Item Controls or
indicating instrument
respectively
ERC
12
ERC
14/16
ERC-Z
12/14/16
Function
1 Keyboard
(CANCODE)
oo oCode settings
Travel programme enable
2 Display instrument
(CANDIS)
oo oOperating hours meter
Battery capacity display
Shows the residual capacity of
the battery as well as the
accumulated operating hours
of the truck.
3 Key switch tt tSwitches control voltage on
and off.
Removing the key secures the
truck against switching on by
unauthorised personnel.
4 Control shaft tt tSteering and braking the truck.
5 Button - warning
signal (horn)
tt tTrigger warning signal.
6 Button - wheel arms
lowering
-- tWheel arms are lowered
with constant speed
7 Button - wheel arms
lifting
-- tWheel arms are lifted
with constant speed
8 Driving regulator tt tControls the driving direction
driving speed.
9 Bumper safety switch tt tPedestrian-controlled operati-
on:
Safety function, which causes
the vehicle to move for about 3
secs in drive direction “R”
(Backward) and then switches
off until the controller is briefly
moved to the neutral position.
Ride-on mode:
Non-functional.
