11.14 EN
132
8.1.2 Emergency Disconnect
CAUTION!
Applying maximum braking can result in accidents
Applying the Emergency Disconnect switch during travel will cause the truck to
decelerate to a halt at maximum force. This may cause the load to slide off the load
handler. There is a higher risk of accidents and injury.
X
Do not use the Emergency Disconnect switch as a service brake.
X
Use the Emergency Disconnect switch during travel only in emergencies.
Z An additional Emergency Disconnect
switch (89) is included for the rotary
seat option.
Applying the Emergency Disconnect
Procedure
• Press the Emergency Disconnect (89).
All electrical travel, steering and hydraulic
functions are cut out. The truck brakes to
a halt at maximum brake force.
8.1.3 Rotary seat button
Z An additional rotary seat button
(190) is included for the rotary seat
option.
