Jungheinrich TFG 670 User Manual

11.14 EN
24
DFG S80-S90
*) The data listed in the table corresponds to the standard version.
TFG 660-690
Model S80 S90
a/2 Safety distance 100 100 mm
h
1
Collapsed height* 3160 3310 mm
h
3
Lift* 3600 3600 mm
h
4
Extended height* 4960 5110 mm
h
6
Overhead guard
height*
2705 2705 mm
h
7
Seat height* 1600 1600 mm
h
10
Coupling height 500 500 mm
Į
Mast tilt, fwd.* 6 6 °
ȕ
Mast tilt, back* 9 9 °
l
1
Length, including
forks*
5640 5840 mm
l
2
Length, including fork
shank*
3840 4040 mm
b
1
Overall width* 2150 2150 mm
s/e/l Fork dimensions* 70/180/
1800
70/180/
1800
mm
m
1
Ground clearance,
laden, below mast*
230 230 mm
m
2
Ground clearance
centre wheelbase*
250 250 mm
Fork carriage ISO
2328 class / type A, B
4 A 4 A mm
b
3
Fork carriage width 2100 2100 mm
Ast Working aisle width for
pallets 800 x 1200
lengthways
5745 5995 mm
Ast Working aisle width for
pallets 1000 x 1200
traverse
5545 5795 mm
Wa Turning radius 3900 3900 mm
b
13
Smallest turning
radius
1490 1490 mm
x Load distance* 700 700 mm
c Load centre of gravity 900 900 mm
y Wheelbase 2545 2745 mm
Type 660 670 680 690
a/2 Safety distance 100 100 100 100 mm
