DFG/TFG 690-S90
Mast chart
V D I 3 5 9 6
Description
Lift h
3
Free lift
h
2
Collapsed
height h
1
Extended
height h
4
Weight
(kg)
690/S80 690/S80
ZT
3600 0 3160 4960 2240
4000 0 3360 5360 2310
4500 0 3610 5860 2435
5000 0 3860 6360 2560
5500 0 4110 6860 2710
6000 0 4360 7360 2860
6500 0 4610 7860 2985
ZZ
3600 1800 3175 4975 2374
4000 2000 3375 5375 2446
4500 2250 3625 5875 2556
5000 2500 3875 6375 2676
5500 2750 4125 6875 2796
6000 3000 4375 7375 2916
6500 3300 4625 7875 3036
DZ
4500 1500 2885 5886 2796
5000 1667 3052 6386 2879
5500 1833 3218 6886 3004
6000 2000 3385 7386 3149
6500 2167 3552 7886 3253
7000 2333 3718 8386 3357
7500 2500 3885 8886 3439
8000 2667 4052 9386 3522
Mast chart
V D I 3 5 9 6
Description
Lift h
3
Free lift
h
2
Collapsed
height h
1
Extended
height h
4
Weight
(kg)
S90 S90
ZT
3600 0 3310 5110 2285
4000 0 3510 5510 2385
4500 0 3760 6010 2510
5000 0 4010 6510 2635
5500 0 4260 7010 2810
6000 0 4510 7510 2935
6500 0 4760 8010 3060
