11.14 EN
92
5.3.2 Adjusting the steering wheel / steering column
CAUTION!
Do not adjust the steering wheel while travelling
Individual steering wheel position
Z The steering wheel can be height- and tilt-adjusted to suit the operator.
Adjusting the Tilt
Procedure
• Pull up on the adjusting lever (174).
• Tilt the steering wheel (175) forward or
backward as required.
• Push the adjusting lever into the centre
position.
The steering column tilt is adjusted.
Adjusting the Height
Procedure
• Push down on the adjusting lever (174).
• Adjust the steering column (4) to the required height.
• Pull the adjusting lever (174) into the centre position.
The steering column height is adjusted.
5.3.3 Adjusting the arm rest
The height and angle of the armrest can be
adjusted with the screw (176).
Procedure
• Turn the screw clockwise - the armrest is
raised.
• Turn the screw anti-clockwise - the armrest
is lowered.
The armrest is adjusted.
174
175
4
