Configuring CLI-Based Packet Mirroring ! 161

Chapter 6: Packet Mirroring

! An interface cannot be both an analyzer port and a mirrored interface at the

same time.

! If you do not specify an analyzer port when using the ip mirror command, the

mirrored traffic is forwarded to the virtual router’s default analyzer port. The

command fails if a default analyzer port is not configured.

! An interface can be mirrored to only one analyzer port at a time.

! If the analyzer port is a shared medium (for example, Ethernet), you must

specify the next-hop address to the remote analyzer device.

! Example

host1(config)#ip mirror atm 3/0.2 fastEthernet 2/0 next-hop 192.168.1.2

! If the remote analyzer device is not directly connected to the E-series router,

you must specify a tunnel as the analyzer port.

! Example

host1(config)#ip mirror atm 3/0.2 tunnel gre:analyzer1

! Use the no version to disable mirroring on the interface.

ip policy

! Use with the secure-input or secure-output keyword to assign a secure IP or

L2TP policy list to the ingress or egress side of an interface.

! This command is visible only to authorized users—the mirror-enable

command must be enabled prior to using this command.

! If you enter the ip policy command with the secure-input or secure-output

keyword and the policy list does not exist, the router creates a policy list with a

default mirror rule that disables mirroring. If you attach this policy list to an

interface, there is no packet mirroring.

! When you use this command to create a secure policy list, statistics-related

keywords are not supported.

! Example

host1(config-if)#ip policy secure-input securePolicy2

! Use the no version to remove the policy list from the interface.

mirror acct-session-id

! Use to configure a packet mirroring session that is based on the Acct-Session-ID

attribute (RADIUS attribute 44) associated with an IP or L2TP subscriber, and to

specify the secure policy that is attached to the subscriber’s interface.

! This command is visible only to authorized users—the mirror-enable

command must be enabled prior to using this command.

! Use the ip keyword to specify an IP subscriber or the l2tp keyword for an L2TP

subscriber.

NOTE: The ip policy command used with the secure-input and secure-output

keywords replaces the ip mirror command, which has been deprecated.
