JUNOSe 7.2.x Policy Management Configuration Guide

6 ! Overview

You can apply policy lists to packets:

! Arriving at an interface (input policy); on IP and IPv6 interfaces the packets

arrive before route lookup

! Arriving at the interface, but after route lookup (secondary input policy);

secondary input policies are supported only on IP and IPv6 interfaces

! Leaving an interface (output policy)

Policy Processing Order on an Interface Stack

For a given interface stack, the router processes the attached policies in the same

order in which normal packets are processed. On ingress interfaces, the router

processes any layer 2 policies first, then moves up the stack and processes any layer

3 policies. On egress interfaces, the router processes the layer 3 policies first,

followed by the layer 2 policies.

For example, Figure 1 shows an IP interface stacked over an ATM interface; both

interfaces have attached policies. At ingress, the router processes the ATM layer

policy first (Policy A), then processes Policy B at the upper (IP) layer. At egress, the

router processes Policy X first, and then processes Policy Y.

Figure 1: Order of Policy Processing

Policy Management Configuration Tasks

Perform the required tasks and also any optional tasks that you need for your policy

management configuration:

1. Create a CLACL (optional).

2. Create a rate-limit profile (optional). See Chapter 3, Creating Rate-Limit Profiles.

3. Create a policy list.

4. Create a classifier group.

5. Create one or more policy rules within the classifier group.

6. Apply a policy list to an interface or profile.

For information on monitoring policies, see Chapter 5, Monitoring Policy

Management.

Ingress Egress

Policy B

Policy A

Policy X

Policy Y

ATM

g013256
