Configuring CLI-Based Packet Mirroring ! 163

Chapter 6: Packet Mirroring

! This command is supported only on an LNS.

! Use the ip keyword to specify an IP subscriber.

! Example

host1(config)#mirror calling-station-id 5551212 ip secure-policy-list

securePolicyIp4

! Use the no version to disable packet mirroring and remove the trigger

configuration that is based on the subscriber’s Calling-Station-ID.

mirror-enable

! Use to enable the use of the secure packet mirroring commands by making the

commands visible in the CLI.

! The mirror-enable command is at access level 12 by default. To provide extra

security, we recommend that you always keep this command at a different

privilege level than the other packet mirroring commands (level 13 by default)

and the standard JUNOSe CLI commands.

For example, if you are using TACACS+ and you have all commands at the

same level, a user looking at the TACACS+ server log is able to view packet

mirroring-related commands and see which users are being mirrored. However,

if you specify that level 12 commands, but not level 13, are sent to the

TACACS+ server, only the mirror-enable command is sent to the TACACS+

server—the other packet mirroring-related commands are not sent to the

server, and they do not appear in the server log.

! This command pertains to the current CLI session; when the session ends, the

secure commands are no longer visible.

! You can control access to this command through the use of authorization

techniques, such as TACACS+ and simple access-list restrictions on vty lines.

! Example

host1#mirror-enable

! Use the no version to disable this command—the packet mirroring commands

are no longer visible. However, active mirroring sessions are not affected, and

continue to be mirrored.

mirror ip-address

! Use to configure a packet mirroring session that is based on an IP subscriber’s

IP address (RADIUS attribute 8), and to specify the secure policy to attach to the

subscriber’s interface.

! This command is visible only to authorized users—the mirror-enable

command must be enabled prior to using this command.

NOTE: The CLI enables you to specify the L2TP keyword for this command;

however, the Calling Station ID attribute is not available to packet mirroring

triggers on the LAC.
