JUNOSe 7.2.x Policy Management Configuration Guide
68 ! Applying Policy Lists to Interfaces and Profiles
A single RADIUS record can contain two policies—one ingress policy and one egress
policy. Each policy can have a maximum of 512 ascend-data filters. Each ascend
data-filter creates a classifier group and the action associated with the classifier
group.
Destination port qualifier 1 byte 0 = no compare
1 = less than
2 = equal to
3 = greater than
4 = not equal to
Reserved 2 bytes –
Marking value 1 byte –
Marking mask 1 byte 0 = no packet marking
Traffic class 1–41 bytes
! 0 = no traffic class (required if there is no
profile)
! First byte specifies the length of the ASCII string,
followed by the ASCII name of the traffic class
! Traffic class must be statically configured
! Name can optionally be null terminated, which
consumes 1 byte
Rate-limit profile 1–41 bytes
! 0 = no rate limit (required if there is no profile)
! First byte specifies the length of the ASCII string,
followed by the ASCII name of the profile
! Profile must be statically configured
! Name can optionally be null terminated, which
consumes 1 byte
Table 6: Ascend-Data-Filter Policy Format (continued)
Action or Classifier Format Comments
NOTE: To create a rate-limit profile, traffic class, or marking rule, you must first
configure the filter/forward field as forward.
