Figure 7: J2350 Hardware Components
Table 6 on page 17 summarizes the physical specifications for the router chassis.
Table 6: J2320 and J2350 Physical Specifications
ValueDescription
■
J2320 Services Router
■
1.75 in. (4.45 cm) high
■
17.51 in. (44.48 cm) wide—18.9 in. (48.01 cm) wide with mounting brackets attached
■
15.1 in. (38.35 cm) deep—plus 0.78 in. (1.98 cm) of hardware that protrudes from the
chassis front
■
J2350 Services Router
■
2.61 in. (6.63 cm) high
■
17.51 in. (44.48 cm) wide—18.9 in. (48.01 cm) wide with mounting brackets attached
■
15.1 in. (38.35 cm) deep—plus 0.78 in. (1.98 cm) of hardware that protrudes from the
chassis front
Chassis dimensions
■
J2320 Services Router
■
Minimum (no PIMs): 14.8 lbs (6.7 kg)
■
Maximum (three PIMs): 15.9 lbs (7.2 kg)
■
J2350 Services Router
■
Minimum (no PIMs): 16.3 lbs (7.4 kg)
■
Maximum (five PIMs): 18.2 lbs (8.3 kg)
Router weight
J2320 and J2350 Services Router Hardware Features ■ 17
Chapter 2: System Overview
