Limitations. The Gigabit Ethernet ePIM has the following limitations:
■ Gigabit Ethernet ePIMs do not support SNMP.
■ Configure Gigabit Ethernet ePIM interfaces up to a maximum MTU size of
9018 bytes.
Installation. You can install Gigabit Ethernet ePIMs in any high-speed slot as follows:
■ J4350—Install up to two Gigabit Ethernet ePIMs in slots 3 and 6.
■ J6350—Install up to four Gigabit Ethernet ePIMs in slots 2, 3, 5, and 6.
NOTE: High-speed slots are labeled with an E on the front-panel slot number diagram.
To install or remove a PIM, see “Replacing a PIM” on page 174.
Interface LEDs. The LINK and TX/RX LEDs indicate link status and activity.
Table 23 on page 54 describes the meaning of the LEDs.
Table 23: Gigabit Ethernet Port LEDs
DescriptionStateColorFunction
Port is online.On steadilyGreen
LINK
Port is offline.OffUnlit
Port is transmitting or receiving traffic.BlinkingGreen
TX/RX
Port might be online, but it is not
receiving traffic.
OffUnlit
For alarms, see the configuring and monitoring alarms information in the J-series
Services Router Administration Guide.
Optical Interface Support. Table 24 on page 54 describes the optical interface
support on the SFP Gigabit Ethernet ePIM over single-mode fiber-optic (SMF) and
multimode fiber-optic (MMF) cables.
Table 24: Optical Interface Support for SFP Gigabit Ethernet ePIM
1000Base-LX Transceiver1000Base-SX TransceiverParameter
10 km (6.2 mi) on 9/125-µm SMF
cable
550 m (1894 ft) on MMF cable
500 m (1640 ft) on 50/125-µm
MMF cable
200 m (656 ft) on 62.5/125-µm
MMF cable
Maximum distance
1270 nm through 1355 nm830 nm through 860 nmTransmitter wavelength
54 ■ Field-Replaceable PIMs
J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
