5. Detach the ESD grounding strap from the site ESD grounding point.
6. Attach an ESD grounding strap to your bare wrist, and connect the other end of the strap to an ESD
grounding point.
7. Place the grounding cable lug over the grounding points on the front of the chassis (see
Figure 4 on page 11).
8. Secure the grounding cable lug with the washers and screws. The holes are sized for SAE 10-32 screws.
Apply 4.34 lb-in. (0.49 Nm) of torque to each screw. Do not overtighten the screw. (Use a number 2
Phillips screwdriver.)
CAUTION: Ensure that each grounding cable lug seats flush against the surface of
the grounding points as you are tightening the screws. Ensure that each screw is
properly threaded into the grounding points. Applying installation torque to the
screw when improperly threaded may result in damage to the terminal.
CAUTION: The maximum torque rating of the grounding screws on the router is
4.34 lb-in. (0.49 Nm). The grounding screws may be damaged if excessive torque
is applied. Use only a torque-controlled driver to tighten screws. Use an
appropriately sized driver, with a maximum torque capacity of 5 lb-in. or less. Ensure
that the driver is undamaged and properly calibrated and that you have been trained
in its use. You may wish to use a driver that is designed to prevent overtorque when
the preset torque level is achieved.
9. Dress the grounding cable, and verify that it does not touch or block access to router components, and
that it does not drape where people could trip on it.
10
