Figure 20: Installing an AC Power Supply
g004700
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
Protective earthing
ESD point
Power supply
ejectors
AC Power
supplies
Air exhaust
Air exhaust
NOTE: The MX960 DC power supplies protrude approximately 2 inches from
the back of the chassis. See Figure 21 on page 27.
