MX5, MX10, MX40, and MX80 Quick Start Description
This Quick Start contains information you need to install and configure the router quickly.
For complete installation instructions, see the MX5, MX10, MX40, and MX80 3D Universal
Edge Router Hardware Guide at http://www.juniper.net/techpubs/.
WARNING: This Quick Start contains a summary of safety warnings in “Safety
Warnings” on page 19. For a complete list of warnings for this router, including
translations, see the MX5, MX10, MX40, and MX80 3D Universal Edge Router
Hardware Guide at http://www.juniper.net/techpubs/.
The MX5, MX10, MX40, and MX80 routers are available as a modular chassis with two
dedicated slots for Modular Interface Cards (MICs) that provide scalable configuration
options. Software licenses allow you to upgrade from one router to another without a
hardware upgrade. The ports are restricted based on the router’s associated license as
follows:
•
MX5 router: allows usage of the MIC slot labeled 1/MIC 0 which comes pre-populated
with the Gigabit Ethernet MIC with SFP.
•
MX10 router: allows usage of the MIC slot labeled 1/MIC 0 which comes pre-populated
with the Gigabit Ethernet MIC with SFP and the second MIC slot labeled 1/MIC 1.
•
MX40 router: allows usage of both MIC slots and ports 0 and 1 of the built-in 10-Gigabit
Ethernet MIC (labeled 0/MIC 0).
•
MX80 router: allows usage of both MIC slots and all four ports of the built-in 10-Gigabit
Ethernet MIC (labeled 0/MIC 0).
A fixed version of the MX80 router (model number: MX80-48T) has 48 fixed
10/100/1000Base-T RJ45 ports in place of the MIC slots.
For a list of MICs supported on the MX5, MX10, MX40, and modular MX80 routers, see
MICs Supported by MX Series Routers in the MX Series Interface Module Reference.
3Copyright © 2015, Juniper Networks, Inc.
MX5, MX10, MX40, and MX80 Quick Start Description
