JA94-N01A Dual Audio Controller - NVG
Installation and Operating Manual
Rev A Page 14
2.6 Installation Kit
The kit required to install this unit is not included with the unit.
The installation kit (Part # INST-JA94) consists of the following:
Quantity Description JAC Part #
1 15 Socket Positions, Zinc Plated, D-Subminiature - Crimp Socket Housing CON-3460-0115
1 37 Socket Positions, Zinc Plated, D-Subminiature - Crimp Socket Housing CON-3460-0137
1 50 Socket Positions, Zinc Plated, D-Subminiature - Crimp Socket Housing CON-3460-0150
1 15 Pin Clamshell, Hardware - Plastic D-Sub Hoods CON-5300-0115
1 37 Pin Clamshell, Hardware - Plastic D-Sub Hoods CON-5300-0137
1 50 Pin Clamshell, Hardware - Plastic D-Sub Hoods CON-5300-0150
102 Machined 20 to 24 AWG wire size range, MIL spec, D-Submin - Crimp Socket CON-3320-2024
3 For Any D-sub Connector, Hardware - Slide Locks - Vertical CON-5275-0050
2 0.625" Inside Diameter, Hardware - Tag Ring CON-5500-0625
2 1" Inside Diameter, Heat Shrink Tube WIR-HTSK-1000
2.6.1 Recommended Crimp tools
Insertion/extraction tool
2.7 Installation Drawings
The drawings and documents required for Installation can be found in Appendix A of this manual.
2.7.1 Generation of Custom Drawings
The interconnects and connector maps in Appendix A of this manual are generic drawings based on the standard
version of the JA94-N01A. However, if a unit has been configured using JAC’s ProCS™ software to change switch
legends or lighting voltages, the software can be used to generate fully customized interconnects and connector
maps for use by the installer.
