JA94-N01A Dual Audio Controller - NVG
Installation and Operating Manual
Rev A Page 2
1.3 Inputs and Outputs
Refer to the JA94-N01A connector maps for the mating connector designators and pin assignments for the
input and output signals.
1.3.1 Inputs
Name
Qty
Type
COM Remote TX Select 6 Control signal
CONFIG DATA TO JA94-N01A 1 Data signal
DIRECT AUDIO 3 Audio signal
ICS Isolate Mode 1 Control signal
ICS PTT 8 Control signal
LIGHTS INPUT 1 Analog control signal
MIC 8 Audio signal
MODE SELECT 1 Multi format signal
MUSIC 4 Audio signal
POWER INPUT 1 Power supply
RX HI/LO 10 Audio signal (6 COMs, 4 NAVs)
TX PTT 5 Control signal
1.3.2 Outputs
Name
Qty
Type
CVR 2 Audio signal
CONFIG DATA FROM JA94-N01A 1 Data signal
Headphones 8 Audio signal (Note: 7 outputs for driving 8 phones)
Transceiver MIC 6 Audio signal
Transmit PTT 6 Active low discrete
RX COMP OUT 2 Audio signal
1.3.3 Bi-directional Ports
Name
Qty
Type
ICS TIE 1 Audio signal
1.4 Specifications
1.4.1 Electrical Specifications
Power Input
Primary nominal voltage 28 Vdc
Maximum voltage 32.2 Vdc
Minimum voltage 22.0 Vdc
Emergency voltage 18.0 Vdc
Power Off Voltage ≤ 15.0 Vdc
Input current 0.95 A max
