Jura ENA 3 Disassembling Manual

Elektroapparate AG
Disassembling manual
Technical Support
Language E
ENA 3 / ENA 5
51/ Open swinging support by pressing the snap-lock 52/ View behind the power print
53/ View of the grinder unit:
 Unscrew 3x TORX 15 and pull out grinder unit
54/ Pull out cover of the grinder funnel
Author: Patrik Studer Checked: Approved: Docu.-name: Ena Disassemble Manual.doc
C:\Users\Admin\Documents\Jura Manuals\Ena\ENA 5\Ena
Disassemble Manual.doc
Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F:
18.10.2007 26.10.2007
Page 10/15

Jura ENA 3 Specifications

General

Type	Coffee
Dimensions (WxDxH)	238 x 360 x 445 mm
Product type	Espresso machine
Capacity in cups	10 cups
Anti-drip function	Yes
Water tank capacity	1.1 L
Maximum operating pressure	15 bar
Lid type	Hinged lid
Product color	Black
Multi beverage	No

Weight and Dimensions

Weight	9300 g
