BELT DRIVE
• Install a suitable pulley on the smooth
shaft as close as possible to the pump: max 35 mm.
• Apply an adequate belt tension (see manufacturer’s data). Max 3000N.
• Do not use driven or driving pulleys with a pitch diameter inferior to 180 mm. Small pulleys
require a high belt tension which may cause premature wear to the bearing or transmission
troubleshooting
NOTE
If the pump PN155 is run through a belt drive, its working pressure must not exceed 1.5 abs.
bars to prevent it from absorbing a power requiring an excessive belt tension. There is no limit
to the operation in vacuum.
Drive min. pulley
pitch diam.
Belts Max. Speed Max. Pressure Max. Vacuum
mm rpm bar abs %
180 XPB x 3 1150 1,5 93
HYDRAULIC D
RIVE
• Motor features
Displacement Max. operating pressure Max pressure draining line Max. press. motor exhaust
cc/rev bar
bar
bar
86 220 5 5
• Fluid: mineral oil for hydraulic systems in compliance with ISO/DIN
Temperature Optimum viscosity Max. viscosity allowed
°C cSt cSt
-20 / +80 12 - 100 750
MAX
3300 N
35 MAX
KEEP AXELS PARALLEL
ALIGN PULLEY GROVES AND
BELTS
CHECK BELT TENSION
D
= 180 MI
