PN155 FL 540 rpm, left rotation (A353219410)
NOTE. The vacuum pum
p PN155 may be equipped with aluminium conveyors.
Kit fixed conveyor Ø100 with valve connection: cod. 18521 035 00
Kit swivelling conveyor Ø100: cod. 18521 040 00 Kit valve connection: cod. 18521 041 00
• Rotary vacuum pump with radial vanes and
air cooling system.
• Automatic lubrication with volumetric pump
and side mounted tank.
• Built-in vacuum-pressure change-over
valve.
•
Non return valve (rubber ball) inside pump
manifold.
• Aluminium conveyors.
• Gear box drive (splined shaft ASAE 1 3/8)
540
rpm or 1000 rpm, left rotation.
• Direct drive with smooth shaft, right or left
rotation.
• Direct drive with splined shaft ASAE 1 3/8, left
rotation.
• Hydraulic drive with gear mo
tor, right rotation.
As model PN155. In addition:
• Extra air injection cooling system.
• High resi
stant vanes.
OTHER FEA
TURES ON REQUEST:
• Rotation other than the standard one.
• Pneumatic or hydraulic actuator for the 4-way
valve.
The vacuum pump PN155 is designed to convey filtered air into systems for the vacuum production or for the
suction of powders or liquid wastes. Any other usage shall be considered improper.
Do not sack toxic substances and inflammable or explosive gasses, since the internal components of the
pump may reach high temperatures.
Liquids or solids infiltrations can seriously damage the pump
Do not run the pump over its designed operating limits (see “Usage limitations): it may break and
transmission can be damaged.
3.2 FEATURES PN155R
4. NORMAL USE
3.1 FEATURES PN155
