Avoid INCORRECT Audio Connection
+
Always connect the audio output of the sampler DIRECTLY to a mixing console, not through
the audio input of the synthesizer. In this picture audio connections are INCORRECT and
leads to a DRASTIC reduction in sound quality. The correct way is shown in previous
picture!
Audio Output Settings
Volume potentiometer is located on the front panel and controls the level of both the headphones
and the main audio outputs located on the rear panel. Headphone is designed to work with low-
impedance headphones.
